| Recommended Operating Frequency Range (TE10) | EIA (GHz) | Min.: 220.0 Max.: 325.0 |
|---|---|---|
| Cut Off for TE10 Mode | Frequency: 176.2 GHz GHz Wavelength: 0.170 cm cm | |
| Power Rating (Megawatts) | 1.25fc - 1.9fc (See Note 1) | Min.: 0.00054 Max.: 0.00076 |
| Theoretical Attenuation | Lowest to Highest db/100ft. | Aluminum Max.: Min.: Brass Max.: Min.: Silver Max.: 529.155 Min.: 358.459 |
| Flange Options | Call Sales (207) 854-1700 | |
| Waveguide Dimensions (Inches) | Inside Width: 0.0340 Height: 0.0170 Tolerance: (+/-) 0.00020 Outside Width: 0.156 dia Height: Tolerance: (+/-) 0.001 | |
| Wall Thickness |
Note 1: True theoretical values at 1 atmos. dry air at 20ºC, no safety factor included.
*Contact Flange
†CPR Flat
††CPR Grooved
